• XY2CH 施耐德拉繩開關（最多至15m 拉繩保護）
  > 拉繩出線方式靈活，可以左出線，或者有出線。
  > IP65防護等級
  > 1NC+1NO 或 2NC 兩種觸點組合
  > 有多種按鈕復位方式可選，戴罩，蘑菇頭，鑰匙等
  > 帶直觀的指示窗口，指示觸點狀態和拉繩張緊度
  > CE，UL，CSA認證
• XY2CE （最多至50m 拉繩保護）
  > IP65防護等級
  > 1NC+1NO，2NC或，2NC+1NO三種觸點組合
  > 有多種按鈕復位方式可選，戴罩，蘑菇頭，鑰匙等
  > 帶直觀的指示窗口，指示觸點狀態和拉繩張緊度
  > CE，UL，CSA認證
• XY2CB （最多至100m或2*100m 拉繩保護）
  > 觸點防護等級IP65，外殼防護等級IP22
  > 1NC+1NO，2NC或，2NC+1NO三種觸點組合
  > 拉桿復位
  > 可選直觀的指示窗口，指示觸點狀態和拉繩張緊度



• 急停拉線開關是一種易于使用和安裝的安全對話產品，產品設計集成了緊湊和人性化的特點，主要功能為對危險機械實現急停區域保護



應用范圍

XY2CH施耐德拉繩開關技術參數表

范圍	Preventa XY2
產品或組件類型	閉鎖急停拉線開關
設備短名	XY2CH
就地信號	不帶指示燈
電纜數量	1
最大拉線長度	15 m
覆蓋顏色	灰色 RAL 7032
復位	通過帶密封套的按鈕
觸點類型和構成	1 NC + 1 NO
拉線固定點	右邊或左邊
連接到端子	螺釘夾緊端子 1 x 0.5...2 x 1.5 mm²

觸線操作	慢中斷
緊固轉距	0,8...1,2 N.m
電纜進線孔	用于Pg 13.5電纜套的3帶孔進線
機械壽命	10000 cycles
電纜卡具之間的距離	5 m
Ie額定工作電流	0,27 A 在 250 V DC-13 , Q600 符合 EN/IEC 60947-5-1 附錄 A 3 A 在 240 V AC-15 , A600 符合 EN/IEC 60947-5-1 附錄 A
Ithe 約定封閉發熱電流	10 A
Ui額定絕緣電壓	300 V 符合 UL 508 300 V 符合 CSA C22-2 No 14 400 V , 污染等級: 3 符合 EN/IEC 60947-1
Uimp額定沖擊耐受電壓	4 kV
強制打開	有 符合 EN/IEC 60947-5-1 款項 3
接線端子間的阻抗	≤ 25 mOhm 符合 EN/IEC 60255-7 級別 3 ≤ 25 mOhm 符合 NF C 93-050 方法 A
短路保護	10 A 熔絲管 , gG 符合 EN/IEC 60269
高度	68 mm
寬度	201 mm
深度	95 mm
產品重量	0,865 kg

注意：XY2CH13250觸點形式是1NC+1NO（一開一閉）不帶指示燈，通過密封式按鈕復位（也可手動復位），電纜長15M，左手或右手側拉線定位點，3個進線口！
XY2CH13270是2NC（2常閉）觸點，也不帶指示燈
